![](https://blogger.googleusercontent.com/img/b/R29vZ2xl/AVvXsEg8M-tchQXjG0Pdql32k_z52YKMqHibmWNi5bDUKQNCMPegXhrbm1IBg4YkdvDYiiAhIkrqdNuIYbasPh6A1qgHdK-TVGM5XCU0cPYkZkwj2Jv6uRBS1jh3q2GJqssXLnhoaq89t2n0bfA/s320/a1.JPG) |
The bike trailer with foldable prop.
|
![](https://blogger.googleusercontent.com/img/b/R29vZ2xl/AVvXsEhqYdjRaMlzrkAWB2RZLEhfUMMWmE_BprTSEECvl6PYl46XoSu5uXgTUv7HLWeD2EcDNu8WwKJgNUmJVjiooq5iDHEQN5dXmCXh5zmaI46hGyPgkczq5oHThuV8DoHgLSLaXX9uJzRBMTI/s320/a2.JPG) |
Folding the prop down helps me get it around the side of the house.
|
![](https://blogger.googleusercontent.com/img/b/R29vZ2xl/AVvXsEht0aEEFA5UuKtqj2thHyP7zYvU-ezEl18Q7mptgK3bDc54J6DuHGeoW62aLD8DkGiuKX2d0P3lJc28x6qOTWnGE0VIVdAgTKn9ZPmjtPa4JoG5Cp1jbpXsOvuV_Hb_M8yU0rvddL0UuBc/s320/a3.JPG) |
The cargo: this is the tetrahedral wheel rim sculpture I discussed in my design blog. In the last few days I made it "a bit less boring" by replacing one of the top rims with a spoked wheel with a cd fan in the centre.
|
![](https://blogger.googleusercontent.com/img/b/R29vZ2xl/AVvXsEgTGbhvP9QbTKSQp3mNDKcpte6hKDisIQ75Ri4R9ddru1NgKPfQvrO_mOd1nLPPlWVLKCnF734VU1nPT8_jrVoupFMHNY_9Qf7-CLepv6fMFAQQEP3XZ7F3s2jTjM3_YSOjZl3kINa2fbc/s320/a4.JPG) |
Backyard trial with the sculpture. This is the sculpture in flat-pack form.
|
![](https://blogger.googleusercontent.com/img/b/R29vZ2xl/AVvXsEgC7NldFlgK3C-8fjq8cvMkKoBwz3qOAd-uIjADZJ2gJQech_e3eJQa_u_iZ5GlRIcwC9bwbnHyELPiPvsAo4LkEuoVgiJCUkvqO1yjvXeRGlJcaczxaRP2V6rTFRL0u8eQRxfwIFzKx6g/s320/a6.JPG) |
Woohoo we're rolling! This is the first time I had it hitched up.
|
![](https://blogger.googleusercontent.com/img/b/R29vZ2xl/AVvXsEhb7BcK41PKoxf4pp17luEdYn2G9YHSZm9KqRTJKpy4RldR08ZQ3flEFHub4_ZhHjTTLiT5m283WG_uYU7L6FE-ZLrTBYXiE85N2qQd-59k-5LERycDqTukXTE4BPk8b0HDQ-dEv4IbT00/s320/a7.JPG) |
Arrival at Wecycle, I was the first there today.
|
![](https://blogger.googleusercontent.com/img/b/R29vZ2xl/AVvXsEgzCRMBCORiocrBG8FzG7KIqf_uAOs1ncD2MnTu0PNNg5PDMlVmi88zRl2bXLacCUjseTsFeUuvXLCJgZO8m3IFmSkDEGE8vD_TWao985JIQPsu2gMNp6HHDvIEOmxQi2y9I13uXvtlQ3g/s320/a8.JPG) |
Set up, a few early arrivals, customers and volunteer Lucas are trickling in.
|
![](https://blogger.googleusercontent.com/img/b/R29vZ2xl/AVvXsEiBe_Gz2BhcjxpFKtomxGje6MFN0JcE1J0BVzFF85Vf9gLlkMruL-m1BmXbbQJOMWGdX0awAnkgWbKCzdasQwoAcc0X6vx11ClD-jOl-lVfIBGOUosZwiEJvXUalSVBBPL7y60HniRSdNY/s320/a9.JPG) |
Just about full swing a few hours later.
|
![](https://blogger.googleusercontent.com/img/b/R29vZ2xl/AVvXsEiM8mAC-T_5f7Elcza5lhFdPYELS4Jh3fcIYAr-EqKpnh4_BDQLRrZhOZ7Jlu9Ek5nQRufZl2odnwG7e7M-IykLf1Fdh-V7fIPEqcMYNaTPr7VnkNtpiMn_9kM5_Is4P1G3PtUz1PaGgBU/s320/a10.JPG) |
I was helping Carlos to check gears on a bike inside (yes, I did some work there) Here he's using his phone to see the L and H marks on the rear derailleur.
|
![](https://blogger.googleusercontent.com/img/b/R29vZ2xl/AVvXsEhuLsc_NUBKKOhKil3FJoNof4spe9xPa4J7X5Fs20QfG4YKL1nsPuH7g68u0pFgPc666U4Ot5TLC8R-4xPMFo4FUBzZ1iV_Gg8bWNmXFA8yPCbE6eO3XjFS1kKZnjIPSmwFdgpvkYuQ37k/s320/a11.JPG) |
Back home
|
![](https://blogger.googleusercontent.com/img/b/R29vZ2xl/AVvXsEhcQ_eBbikKIXOFmSg90f6lDANwczOY8O8jC7Ft62ly2gF02aoHhY_b3tsjmg3Gd5lJv40gMzld3wKW_CFlHqYKRK4KfKmYoHgz-yygX1CM0bKBdlnamvFhTMB838Saprxd7YH6PLKxAlw/s320/a13.JPG) |
This plug goes into the main frame beam of the Vuong trike. The bolt at the fop secures it in the frame.
|
![](https://blogger.googleusercontent.com/img/b/R29vZ2xl/AVvXsEgtEuYrd8_qmC-YN6Drl__g7Kg4o-hjJ9A_xL7VFYzzq1-PWtMpKmUr5eWEKlEwDwt9GzyLVNdpfar4AQdnJBwB8wigM7U18p0tcRXLpcj_SCF6-iu2Ux9lvGrjA73PAPYMlD9fuFAgB7I/s320/a14.JPG) |
Another view of the hitch adapter. I think the steel part was once a bit of a chainstay.
|
![](https://blogger.googleusercontent.com/img/b/R29vZ2xl/AVvXsEgc3h3bMOxHC_bzoRCAKaNfNS3BRzvpxigkj2EHUoxrAmpnES1Ikb2yCg8RU4oxNYrW6wjouMdoYPFcq92G4CBLFnD_KvHRiDqlZl99SeAfqdIc5dGl5J49JCMLPjyh8hLeOKX4BHOpyRw/s320/a5.JPG) |
Trailer hitch on trike. This particular trailer fits in with the asymmetry of the back wheels.
|
Hi
For a few days I've been finishing off a sculpture in our backyard, and it had its public debut and first road trip today. A bit after the sculpture was done, I dragged a barely started hard rubbish trailer project around from the side of the house and got to work. Firstly I made a full plywood deck, then a few pins to go in the sculptures spoke holes. Lastly I made a folding prop for the rim sculpture.
It wasn't till this morning when I was actually using it that I tried the trailer and it worked very well. But even by my standards this rig is conspicuous. Anyway the sculpture went down well at Wecycle at Batman Park, where I volunteer on Saturdays fixing bikes for refugees. Here is a video of it reflecting light from the sun in our backyard.
I'm planning another trailer, this time for my electric Voung leaning trike, and it will be used to tow a surfboard.
Regards
Steve Nurse
